Display

• Type: OLED

• Size: 77" (76.7") / 195 cm

• Resolution: 3840 × 2160 (4K UHD, QFHD)

• Aspect Ratio: 16:9

• Viewing Angle: 178° (89/89)

• Refresh Rate (Native): 120Hz

• HDR Support: HDR10, HLG, Dolby Vision

• Processor: XR Processor

• Picture Modes: Vivid, Standard, Cinema, Professional, Calm, Photo, IMAX Enhanced, Dolby Vision (Vivid/Bright/Dark/Game), FPS game, RTS game

• Motion Enhancement: XR OLED Motion (Auto)

Audio

• Audio Power Output: 13W + 13W + 10W + 10W + 10W

• Speaker Type: Acoustic Surface Audio+

• Configuration: Actuator × 2, Tweeter × 2, Subwoofer × 1

• Sound Modes: S-Force Front Surround, DTS (DTS:X, DTS-HD, DTS Digital Surround), Dolby Audio & Dolby Atmos

• Features: Acoustic Center Sync, Vertical Surround Engine, Room & User Position Compensation

Smart Features

• Operating System: Google TV (Android 12)

• On-board Storage: 32GB

• App Store: Google Play Store

• Voice Control: Yes (Voice Remote, Built-in Mic)

• Casting: Chromecast built-in, Apple AirPlay, Apple HomeKit

• Streaming Services: SONY PICTURES CORE, Netflix Calibrated Mode, IMAX Enhanced, Prime Video Calibrated Mode

Connectivity

• HDMI Inputs: 4 (HDMI 2.1 with 4K120, eARC, VRR, ALLM, SBTM)

• USB Ports: 2 (Side)

• Ethernet: 1 (Side)

• RF (Terrestrial/Cable): 1 (Side)

• IF (Satellite): 2 (Side)

• Digital Audio Output (Optical): 1 (Side)

• Wireless: Wi-Fi (a/b/g/n/ac/ax, 2.4/5/6GHz), Bluetooth 5.3

• CI+: Yes

Dimensions & Weight

• Without Stand (W × H × D): Approx. 171.3 × 98.4 × 3.8 cm

• Package (W × H × D): Approx. 191.2 × 111.5 × 19.1 cm

• Weight Without Stand: Approx. 32.3 kg

• Weight with Package: Approx. 44 kg

• VESA Mount: 300 × 300 mm

Power

• Voltage/Frequency: 220–240V AC, 50 Hz

• Rated Power Consumption: 619 W

• Standby Power: 0.50 W

• Networked Standby Power: 0.5–2.0 W (depending on connection)

• Mercury Content: 0.0 mg

• Lead Content: Yes

Accessories Included

• Remote Control: RMF-TX820U & RMT-TX450E

• Table Top Stand (assembly required)

• Floor Stand

• AC Power Cord (EU/Swiss/Asia variants)

• IR Blaster

• Support Belt

• Batteries (LR03 + R03)

• Setup Guides & Manuals

Optional Accessories

• Sony Wall-Mount Bracket

• Floor Stand (optional model)

• Camera Unit (CMU-BC1)
