System Format
2–Way
Channels
1
Frequency Response, Installed (-6dB)
40 Hz – 30 kHz?
Nominal Impedance
8 ohm
Minimum Impedance (20Hz to 20kHz)
6.5 Ohm @ 200 Hz
(6.2 Ohm @ 20 kHz)
Sensitivity (2.83Vrms@1m, Installed)
84 dB
Maximum Peak SPL* (single speaker @ 1m Z-Weighted)
110 dB
Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)
50 W
Recommended Amplifier Power (RMS into 8 OHM, Music Signal)
25 – 100 W
Drive Unit Complement
1 x 5" (127 mm) C-CAM mid-bass driver
1 x 1" (25 mm) C-CAM tweeter
Crossover Frequency
LF/HF: 2.5 kHz
Mounting Depth
85 mm (33/8")
Cutout L x W
527 x 198 mm (203/4 x 713/16")
External Dimensions (Including Grille (H x W x D))
560 x 231 x 90 mm (221/16 x 91/8 x 39/16")
Weight (each)
2.6 kg (5 lb 11 oz)
Pre-Construction Bracket
WM-B
Cabinet Finish
Matt black & Orange?
Sold As
Single Unit
If you're looking for a Multibuy saving deal on 3 or more items, we can usually offer you a discount on our already competitive prices.
Simply click the Multibuy Saving button on any product page to build up your list of required products. Once you have built your list, please confirm your required quantities, complete your details and click the "Request Quote" button.
We will contact you by telephone or email within 48 hours to advise you of our best price.
Click the "Add this product" button to add this item to your list and we'll get back to you within 24 hours. Alternatively, please email us on [email protected].
